Mechanical Centerless Grinding Machine
| Specification | MCLG50 | MCLG75 | MCLG100 |
| Capacity | |||
| Maximum Grinding Dia. | 40 mm | 75 mm | 100 mm |
| Minimum Grinding Dia. | 1 mm | 1 mm | 2 mm |
| Maximum Length in Through Feed | 150 mm | 200 mm | 250 mm |
| Grinding Wheel Size (D x W x H) mm | 250 x 50 x 76.2 | 300 x 80 x 127 | 350 x 100 x 127 |
| Grinding Wheel Speed | 2300 rpm | 1900 rpm | 1700 rpm |
| Regulating Wheel Head | |||
| Regulating Wheel Size (D x W x H) mm | 180 x 50 x 76.2 | 200 x 80 x 76.2 | 230 x 100 x 76.2 |
| Regulating Wheel Speed | 16 – 30 – 55 – 100 | 16 – 30 – 55 – 100 | 16 – 30 – 55 – 100 |
| Swivel of Regulating Wheel Head | ± 5 Degree | ± 5 Degree | ± 5 Degree |
| Grinding Wheel & Regulating Wheel Head | Manual Dresser | Manual Dresser | Manual Dresser |
| Electricals | |||
| Wheel Head Electric Motor (HP / RPM) | 2 / 1440 | 3 / 1440 | 5 / 1440 |
| Regulating Wheel Head Electric Motor (HP / RPM) | 0.5 / 1440 | 0.5 / 1440 | 1 / 1440 |
| Coolant Pump (HP / RPM) | 0.15 / 2800 | 0.15 / 2800 | 0.15 / 2800 |
Standard Accessories
- Grinding Wheel With Flange
- Regulating Wheel With Flange
- Balancing Blocks
- Work Rest
- Levelling For Work Rest
- Wheel Head Motor & Work Head Motor
- Coolant Tank With Pump And Piping
- Dressing Attachment (Manual)
- Wheel Flange Extractor
- V – Belt & Pulley Cover
- Lubricant Oil Pump
- Electric Panel With Push Buttons
Optional Accessories
- Additional Grinding Wheel Flange
- Additional Regulating Wheel Flange
- Grinding Wheel Balancing Blocks
- Wheel Balancing Arbour
- Wheel Balancing Stand
- Hydraulic Dressing Attachment
- Magnetic Separator
- Carbide Work Rest Blade for Straight Grinding
- Work Rest Blade Hardened for Straight Grinding
- Micro Feed Attachment
- Automatic Lubrication Oil Pump
- VFD
- Turcite Coated Slide
- Machine Lamp
- Vibrating Pad
- Bar Feeding Attachment
- DRO Unit
As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice
