Pneumatic Rocker Arm Type Spot Welding Machine
| Model | Unit | PRSW 10 | PRSW 12 | PRSW 15 |
| Rating @50% Duty Cycle | K.V.A. | 10 | 12 | 15 |
| Input Supply | Volts | 380/440 | 380/440 | 380/440 |
| Phase | 2 | 2 | 2 | |
| 2 Line Of 3 Phase Supply | ||||
| Insulation Class | A (CU.) | A (CU.) | A (CU.) | |
| Nominal Throat Clearance | mm | 250 | 250 | 250 |
| Throat Depth | cm | 50 | 50 | 50 |
| Max. Available Short Circuit Current | K. Amps | 7.5 | 8 | 10 |
| Max. Electrode Force @ 6 kg/cm² | 450 | 450 | 450 | |
| Max.Upper Electrode Stroke | mm | 50 | 50 | 50 |
| Colling For Arms & Electrode | Water | |||
| Colling | Natural Air | |||
| Approx Dimension In | Height | 1280 mm | 1280 mm | 1280 mm |
| Length | 660 mm | 660 mm | 660 mm | |
| Wight | 465 mm | 465 mm | 465 mm | |
| Approx Weight 100% Copper | 172 kg | 175 kg | 180 kg | |
| Approx Weight Semi – Copper | 165 kg | 167 kg | 173 kg | |
| User Has To Provide The Following Services | ||||
| Size Of Main Supply Copper Cable | MM² | 12 | 12 | 16 |
| Recommended Switch Rating | Amps | 24 | 32 | 32 |
| Delayed Action Fuse Rating | Amps | 20 | 20 | 32 |
| External Water Supply At Max. Temp. 30°c | Lit./Min | 5 | 5 | 6 |
As improvements are constantly made in our machines the above specifications and dimensions are subject to modify without any prior notice
